будут описаны первые шаги в настройке Extreme Networks switch, на данный момент в формате не обработанной личной заметки
AGL3-sw1
Connecting a Switch to the Management Console
Connect each switch to a central console to enable direct local management of the switch.
Each switch should be connected to a management console – a terminal or PC with terminal-emulation software. For all Extreme Networks switches, the terminal or PC must be configured with the following settings:
Baud rate: 9600 (see note)
Data bits: 8
Stop bit: 1
Parity: None
Flow control: XON/XOFF
Set the baud rate to 115200 when using the RJ45 Ethernet management port on an X690 or X870 series switch.
Начальные шаги: Перезагрузите коммутатор с конфигурацией по умолчанию
Подключитесь к коммутатору через консольное соединение.
Выключите и выключите выключатель.
Во время загрузки нажмите и удерживайте клавишу пробела, чтобы войти в bootrom.
Extreme Networks
Alternate BootStrap Image
Starting CRC of Default image
Using Default image …
Extreme Networks
Default BootLoader Image
DRAM Post
Press and hold the to enter the bootrom.
В bootrom введите следующие команды, чтобы выбрать конфигурацию по умолчанию для загрузки:
Если ваша версия bootrom 2.0.2.1 опция config none недоступна, обновите bootrom, чтобы решить эту проблему.
BootRom > config none
BootRom > boot
Теперь коммутатор должен загрузиться с заводской конфигурацией по умолчанию. Имя пользователя:admin, Пароль:<пустой>
unconfigure switch all
enter failsafe user name: j.lisck
X440G2-12p-10G4.* # configure account “admin” ?
Execute the command
encrypted Password is Encrypted
password Change account password
password-policy Account password policy
configure account “user”
-
X440G2-12p-10G4.* # configure snmp sysName “X440G2[AGL3-SW1]”
configure snmp sysLocation “"
configure snmp sysContact "” -
X440G2[AGL3-SW1].9 # configure sntp-client primary 0.ru.pool.ntp.org
- X440G2[AGL3-SW1].10 # configure sntp-client secondary 1.ru.pool.ntp.org
- X440G2[AGL3-SW1].11 # configure sntp-client secondary 2.ru.pool.ntp.org
- X440G2[AGL3-SW1].12 # configure sntp-client secondary 3.ru.pool.ntp.org
- X440G2[AGL3-SW1].13 # configure sntp-client update-interval 520
- X440G2[AGL3-SW1].14 # configure timezone +180
- X440G2[AGL3-SW1].15 # show sntp-client
configure vlan Mgmt ipaddress 192.168.88.2 255.255.255.0
enable ipforwarding
enable web http
configure vlan Default ipaddress 192.168.88.102/24
configure bootprelay add 192.168.88.1 vr VR-Default
enable bootprelay ipv4 vlan Default
configure vlan Default add ports 1-12 untagged
configure ssh2 key
\ enable ssh2
\enable ssh2 vr all
vi ssh.pol
enable ssh2 access-profile ssh.pol port 22 vr all
Entry AllowTheseSubnets {
if match any {
source-address 192.168.88.0 /24;
source-address 10.10.0.0 /24;
}
Then
{
permit;
}
}
~
- /usr/local/cfg/ssh.pol 1/10 10%
esc → :wq
enable ssh2 access-profile ssh.pol
check policy ssh
configure sys-recovery-level switch reset
show switch management
Step 4 (Optional). Additional Options
4-1. Enable ssh only on VR-Mgmt
Use the following command if you want to enable ssh only on Mgmt Virtual Router (VR-Mgmt).
enable ssh2 vr VR-Mgmt
4-2. Change SSH port
Use the following command if you want to change SSH port from the default TCP/22.
enable ssh2 port TCP_port_number
4-3. Restrict SSH access
Use the following command to restrict SSH access from specific IP addresses.
enable ssh2 access-profile policy_name.pol
enable stacking-support
reboot
enable stacking
/////////////////////////////////////
configure vlan Mgmt ipaddress 192.168.1.1 255.255.255.0
configure vlan Default ipaddress 10.101.15.240 255.255.0.0
configure iproute add default 10.101.0.1
configure vlan “Default” add ports all untagged
enable ipforwarding vlan “Default”
Mgmt — это отдельный физический разъем.
Он всего 100мбит, используется только для управления железкой.
Мы же используем для управления интерфейс в первом влане.
Вешаем адрес по умолчанию на интерфейс в влане, не забываем прописать дефолтный шлюз,
добавляем туда все порты без тегирования (по умолчанию все закрыто) и обязательно включаем ipforwarding в нашем влане-1. Иначе доступа по сети не будет.
SNMPv3 requires username/passwords to authenticate and encrypt SNMP messages.
Would you like to create an SNMPv3 user? [Y/n/q]:
AGL3-SW2
enter failsafe user name: j.lisck
configure account “admin”
configure account “user”
configure snmp sysName “X440G2[AGL3-SW2]”
configure snmp sysLocation “"
configure snmp sysContact "”
\\ configure sntp-client primary 0.ru.pool.ntp.org
* X440G2[AGL3-SW1].10 # configure sntp-client secondary 1.ru.pool.ntp.org
* X440G2[AGL3-SW1].11 # configure sntp-client secondary 2.ru.pool.ntp.org
* X440G2[AGL3-SW1].12 # configure sntp-client secondary 3.ru.pool.ntp.org
* X440G2[AGL3-SW1].13 # configure sntp-client update-interval 520
* X440G2[AGL3-SW1].14 # configure timezone +180
* X440G2[AGL3-SW1].15 # show sntp-client
configure vlan Mgmt ipaddress 192.168.88.3 255.255.255.0
enable ipforwarding
enable web http
configure vlan Default ipaddress 192.168.88.103/24
configure bootprelay add 192.168.88.1 vr VR-Default
enable bootprelay ipv4 vlan Default
configure vlan Default add ports 1-12 untagged
vi ssh.pol
Entry AllowTheseSubnets {
if match any {
source-address 192.168.88.0 /24;
source-address 10.10.0.0 /24;
}
Then
{
permit;
}
}
~
- /usr/local/cfg/ssh.pol 1/10 10%
esc → :wq
enable ssh2 access-profile ssh.pol port 22 vr all
enable ssh2 access-profile ssh.pol
enable stacking-support
reboot
configure sharing 1 lacp system-priority 1
enable sharing 1:1 grouping 1:1-5, 2:1-5 algorithm address-based custom lacp
////
configure slot 8 module X670V-48x
enable sharing 8:1 grouping 8:1, 1:1-5, 2:1-5 algorithm address-based custom lacp
configure sharing 8:1 add ports 1:48, 2:48
enable ports 1:48, 2:48
disable ports 1:1, 2:1
configure sharing 8:1 delete ports 1:1, 2:1
///
enable sharing 1:11 grouping 1:11, 2:11 algorithm address-based custom lacp
configure ports 1:8 display-string NUC_homeassistant
configure ports 2:9 display-string AP1_MeC
enable sharing 1:13 grouping 1:13, 2:13 algorithm address-based lacp
configure ports 1:8 display-string cam1
show ports description
enable jumbo-frame ports all
configure ssl certificate privkeylen 2048 country RU organization manuala.ru common-name a
gl3-sw1.*****.ru
enable web https
show configuration detail thttpd
show ssl
show ports configuration
///
download image 192.168.1.1 summitX-21.1.4.4-patch1-3.xos vr “VR-Default” inactive
